P-12 is a High-Performance, Long range UHF RFID Integrated Reader with a 12dBi Antenna, an RS232 interface, and a reading distance of up to 25 meters.
| Parameter | Specification / Standard |
|---|---|
| Frequency | 865–868 MHz (India/EU) / 902–928 MHz (US) |
| Protocol Standard | ISO 18000-6C (EPC Gen 2) |
| Built-in Antenna | 12 dBi polarization antenna |
| RF Output Power | 30 dBm (adjustable) |
| Reading Distance | Up to 20 m (ideal) (tag & environment dependent, adjustable) |
| Working Mode | Active / Trigger / Answer mode |
| Special Functions | Password mode, RSSI support |
| RSSI | Supported |
| Reading Speed | Up to 100 pieces/second |
| Antenna Polarisation | Circular/Linear |
| Indicator | LED light — Red & Green LED + Buzzer |
| Standard Interface | RS232 (TTL), Wiegand 26 |
| Optional Interface | TCP/IP (Ethernet), POE, Wi-Fi |
| Power Supply | DC 9V 3A / 12V 2A |
| Material | ABS + die-cast aluminium |
| Color | White |
| IP Protection | IP65 (waterproof & dustproof) |
| Dimensions | 445 × 445 × 55 mm |
| Net Weight | 3.5 kg |
| Operating Temp | -10 °C to +55 °C |
| Storage Temp | -20 °C to +75 °C |
| Package Size | 600 × 500 × 120 mm |
| Package Gross Weight | 5.0 kg |
| SDK | Demo software, API, examples & user manuals |
| Development Languages | C#, Delphi, Java, Python, VB and other languages |
P-12 is a High-Performance, Long range UHF RFID Integrated Reader with a 12dBi Antenna, an RS232 interface, and a reading distance of up to 25 meters.
| Frequency | 865–868 MHz (India/EU) / 902–928 MHz (US) |
| Protocol Standard | ISO 18000-6C (EPC Gen 2) |
| Built-in Antenna | 12 dBi polarization antenna |
| RF Output Power | 30 dBm (adjustable) |
| Reading Distance | Up to 20 m (ideal) (tag & environment dependent, adjustable) |
| Working Mode | Active / Trigger / Answer mode |
| Special Functions | Password mode, RSSI support |
| RSSI | Supported |
| Reading Speed | Up to 100 pieces/second |
| Antenna Polarisation | Circular/Linear |
| Indicator | LED light — Red & Green LED + Buzzer |
| Standard Interface | RS232 (TTL), Wiegand 26 |
| Optional Interface | TCP/IP (Ethernet), POE, Wi-Fi |
| Power Supply | DC 9V 3A / 12V 2A |
| Material | ABS + die-cast aluminium |
| Color | White |
| IP Protection | IP65 (waterproof & dustproof) |
| Dimensions | 445 × 445 × 55 mm |
| Net Weight | 3.5 kg |
| Operating Temp | -10 °C to +55 °C |
| Storage Temp | -20 °C to +75 °C |
| Package Size | 600 × 500 × 120 mm |
| Package Gross Weight | 5.0 kg |
| SDK | Demo software, API, examples & user manuals |
| Development Languages | C#, Delphi, Java, Python, VB and other languages |
The Integrated RFID Reader (P-12) operates at 865–868 MHz (India/EU) / 902–928 MHz (US). India's UHF RFID allocation is the 865–867 MHz band, so confirm the regional variant when ordering — POXO supplies WPC/ETA-compliant units for Indian deployments.
Published read range for the Integrated RFID Reader (P-12) is Up to 20 m (ideal) (tag & environment dependent, adjustable). Real-world range varies with tag type, antenna gain, mounting position, and nearby metal or liquids, so POXO validates read points on-site before go-live.
Yes — Demo software, API, examples & user manuals. Request access through the POXO Developer Zone and our integration team will supply the libraries and sample code for your platform.
The Integrated RFID Reader (P-12) runs on DC 9V 3A / 12V 2A. POXO covers power and cabling requirements in the site survey so panel and PoE provisioning is planned before installation.
It depends on the model — integrated readers have a built-in antenna, while multi-port fixed readers connect several external antennas to cover dock doors, portals, or conveyor lines. Our engineers size the antenna count during the site survey.
Interested in this hardware model? Fill out the details below, and our RFID architects will share a customized proposal.
Hardware that pairs with the Integrated RFID Reader (P-12) in a complete POXO system.
