The P-9 Integrated RFID Reader is a high-performance 9 dBi reader for outdoor environments. Ideal for smart parking systems, gate access, and tracking.
| Parameter | Specification / Standard |
|---|---|
| Frequency | 865–868 MHz (India/EU) / 902–928 MHz (US) |
| Protocol Standard | ISO 18000-6C (EPC Gen 2) |
| Built-in Antenna | 9 dBi circular polarization |
| RF Output Power | 0 dBm – 26 dBm (adjustable) |
| Reading Distance | Up to 12 m (ideal) (tag & environment dependent, adjustable) |
| Working Mode | Active / Trigger / Answer mode |
| Special Functions | Password mode, Mask mode, RSSI support |
| RSSI | Supported |
| Indicator | LED light — Red & Green LED + Buzzer |
| Standard Interface | RS232 (TTL / RS485), Wiegand, Relay |
| Optional Interface | TCP/IP (Ethernet), POE, Wi-Fi |
| Customizable Interface | USB, TTL, RS485 |
| Power Supply | DC 12V 2A |
| Material | ABS |
| Color | White |
| IP Protection | IP65 (waterproof & dustproof) |
| Dimensions | 260 × 260 × 60 mm |
| Net Weight | 1.2 kg |
| Operating Temp | -10 °C to +55 °C |
| Storage Temp | -20 °C to +75 °C |
| SDK | Demo software, API, examples & user manuals |
| Development Languages | C#, Delphi, Java, Python, VB and other languages |
| Firmware | Online upgrade supported |
The P-9 Integrated RFID Reader is a high-performance 9 dBi reader for outdoor environments. Ideal for smart parking systems, gate access, and tracking.
| Frequency | 865–868 MHz (India/EU) / 902–928 MHz (US) |
| Protocol Standard | ISO 18000-6C (EPC Gen 2) |
| Built-in Antenna | 9 dBi circular polarization |
| RF Output Power | 0 dBm – 26 dBm (adjustable) |
| Reading Distance | Up to 12 m (ideal) (tag & environment dependent, adjustable) |
| Working Mode | Active / Trigger / Answer mode |
| Special Functions | Password mode, Mask mode, RSSI support |
| RSSI | Supported |
| Indicator | LED light — Red & Green LED + Buzzer |
| Standard Interface | RS232 (TTL / RS485), Wiegand, Relay |
| Optional Interface | TCP/IP (Ethernet), POE, Wi-Fi |
| Customizable Interface | USB, TTL, RS485 |
| Power Supply | DC 12V 2A |
| Material | ABS |
| Color | White |
| IP Protection | IP65 (waterproof & dustproof) |
| Dimensions | 260 × 260 × 60 mm |
| Net Weight | 1.2 kg |
| Operating Temp | -10 °C to +55 °C |
| Storage Temp | -20 °C to +75 °C |
| SDK | Demo software, API, examples & user manuals |
| Development Languages | C#, Delphi, Java, Python, VB and other languages |
| Firmware | Online upgrade supported |
The Integrated RFID Reader (P-9) operates at 865–868 MHz (India/EU) / 902–928 MHz (US). India's UHF RFID allocation is the 865–867 MHz band, so confirm the regional variant when ordering — POXO supplies WPC/ETA-compliant units for Indian deployments.
Published read range for the Integrated RFID Reader (P-9) is Up to 12 m (ideal) (tag & environment dependent, adjustable). Real-world range varies with tag type, antenna gain, mounting position, and nearby metal or liquids, so POXO validates read points on-site before go-live.
Yes — Demo software, API, examples & user manuals. Request access through the POXO Developer Zone and our integration team will supply the libraries and sample code for your platform.
The Integrated RFID Reader (P-9) runs on DC 12V 2A. POXO covers power and cabling requirements in the site survey so panel and PoE provisioning is planned before installation.
It depends on the model — integrated readers have a built-in antenna, while multi-port fixed readers connect several external antennas to cover dock doors, portals, or conveyor lines. Our engineers size the antenna count during the site survey.
